Fresh Stock ISC RP702 Single Progress Capture Pulley

Product Description

ISC Progress Capture Pulleys can be used vertically, for lifting and lowering applications and horizontally, for line tensioning. Available in both single or double sheave models. The cam is used to capture progress and prevent dropping of the load while hauling, but can be opened and captivated to allow for smooth lowering. The ISC Progress Capture Pulley features a new lightweight center plate, re-positioned wheel to reduce rope friction and a rated becket, through which most carabiners can be fully rotated. The RP702 is fitted with tamper-proof rivets and is individually serial numbered. The cam-face is coned to minimize rope wear.

Directional Felling
For our forestry customers using capstan winches, one of the questions we get quite often is how does one hold tension on a tree to control the felling direction? Well, this device works perfectly to do exactly that. Check out the video to see it in action, and also how to set it up from the very beginning.

• Use with ropes from 3/8″ – 1/2″

View AllClose

Specifications

MPN—–RP702A1
Frame Size—–Large
Rope Size—–1/2"
Sheave Count—–Single
Type—–Hauling / Uplift
Material—–Aluminum
Color—–Red
WLL (lbs)—–1764
Breaking Strength (lbs)—–8992
Breaking Strength (kN)—–40
Swivel—–No
Approx. Weight (lbs)—–1.44
Country of Origin—–Wales
