Pelican 1" x 125 ft Double Braid Polyester Digger Derrick Winch Line Final Sale

Product Description

Double Braid Polyester Winch Line Assemblies – Pre-Spliced Double Eye (Utility Tugger / Digger Derrick)

The Double Braid Polyester Winch Line Assemblies are heavy-duty winch ropes built for big utility trucks used in pole-setting and high-force pulling — including digger derrick trucks, utility tuggers, and other line-construction winch applications. Constructed from double braid polyester, these assemblies deliver excellent strength, low stretch, and dependable performance in demanding field conditions.

Each stocked assembly is urethane coated for added abrasion resistance and is pre-spliced with an eye on each end for fast, field-ready setup. (Eye-splice winch lines are commonly used for attaching to hooks, links, and rigging hardware in utility pulling systems.)

Pro Tip: Spec your winch line by diameter + length + termination. These are stocked as double-eye, urethane-coated assemblies for quick changeouts and consistent fit on utility truck winches.

Stocked Assemblies & Specifications

Key Benefits

• High-strength double braid polyester engineered for high-force pulling
• Low stretch for controlled load handling and precise winch response
• Excellent UV and moisture resistance for outdoor utility environments
• Abrasion resistant urethane coating for extended service life
• Pre-spliced, double-eye assemblies for fast changeouts and reliable connections
• Balanced construction for consistent performance under load

Ideal Applications

• Utility winch lines on digger derrick trucks
• Pole setting and line construction pulling
• Tugger truck operations
• Cable pulling and stringing support where a winch line assembly is required

Working Load & Important Safety Information

Minimum Breaking Strength (MBS) values shown are average break strengths and are provided for comparison purposes only. They must not be used as Working Load Limits (WLL).

• A minimum 5:1 design factor is commonly recommended for general rigging and winch pulling operations unless otherwise specified by regulation, engineering analysis, or site policy.
• Working Load Limit (WLL) should be calculated as: Minimum Breaking Strength ÷ Design Factor
• Final WLL must be determined by a qualified person familiar with the complete system and application.
• Always account for dynamic forces including shock loading, winch acceleration, line angle reductions, block efficiency, hardware ratings, and system angles.
• Use only appropriate hardware and connection methods rated for the intended pull.

Polyester Winch Line Considerations

• Double braid polyester has low stretch compared to nylon. Avoid sudden shock loading, as loads transfer more directly to hardware and anchor points.
• Avoid excessive heat buildup on the winch drum. Do not allow rope to slip under load.
• Glazing, hard spots, or fused fibers may indicate heat damage and require removal from service.

Inspection & Removal From Service

• Inspect before each use for cuts, abrasion, glazing, crushed fibers, pulled strands, or chemical damage.
• Remove from service if core fibers are visible, if significant diameter reduction is observed, or if structural damage is present.
• Remove from service if performance is questionable.
• This product is not intended for lifting or supporting personnel.

Need a different termination, custom length, or bulk quantities? Contact us for custom double braid polyester winch line assemblies built for your truck and application.

View AllClose

Specifications

MPN—–A1A-32CY-125EE
Size—–1"
Type—–Synthetic
Fiber—–Polyester
Color—–Yellow
Length (ft)—–125
Breaking Strength (lbs)—–33500
Overhead Lifting Rated—–Yes
Approx. Weight (lbs)—–45
Country of Origin—–USA
